Touch Panel
We ensure greater transparency
In demanding applications, high-value touch panels are used as decentralized operating and display devices and for process visualization and optimization. They are available in scalable diagonals and for almost any mounting situation and are equipped with high-quality capacitive touch displays. Various interfaces are available for communication with control systems and peripheral devices as well as with hierarchical control systems.
- High-quality visualization
High-resolution displays with wide viewing angle offer best-possible image quality
- Low-power to high-performance
Scalable in display size and processor performance
- Software-based solution
Rely on our tools for quick and easy visualization
- Easy configuration
Sophisticated software tools for quick and easy panel adaptation in line with customer requirements
WP Web Panel 4X, 6X
Innovative Web Panel with QIWI Software Toolkit
- Arm® i.MX8M Mini 4 Core 1.6 GHz
- Arm® i.MX8M Plus 4 Core 1.6 GHz
- Higher Performance with modern Arm® Quad Core CPU
Accessories
- No accessories
Software
- Embedded Linux (Yoctro Distribution)
- QIWI Toolkit
- Optional CODESYS® SoftPLC
Technical Data
Function | WP 4x with Arm® i.MX8M Mini | WP 6x with Arm® i.MX8M Plus |
Touch | ||
PCAP Multitouch, flush glass surface | ||
Processor | ||
Arm® i.MX8M Mini 4 Core 1.6 GHz | Arm® i.MX8M Plus 4 Core 1.6 GHz | |
Memory | ||
RAM | 1 GB DDR4 (up to 2 GB) | 1 GB DDR4 (up to 2 GB) |
FLASH | 4 GB eMMC (up to 32 GByte) | 4 GB eMMC (up to 32 GB) |
microSD Card Slot (up to SDXC format) | microSD Card Slot (up to SDXC format) | |
Interfaces | ||
2x USB 2.0 (Host) 1x Ethernet (10/100/1000) | 2x USB 2.0 (Host) 1x Ethernet (10/100/1000) | |
Power Supply | ||
24 V DC ±20 % | ||
EMC | ||
EN 61000-6-2 (immunity), EN 61000-6-4 (emission) | ||
Certifications | ||
CE (UL, cUL planned) | CE, (UL/cUL planned) | |
Protection glass/Mechanical | ||
Front IP65 in Aluminum, backside IP20 in stainless steel/Fixing elements for quick mounting (portrait or landscape) (Hoch- oder Querformat) | ||
Environment | ||
Operating temperature | 0 °C…+55 °C (optional -20 °C ... +55 °C) | |
Cooling | Fanless | |
Shock | EN 60068-2-27: 15G 11ms (half sine) | |
Vibration | EN 60068-2-6: 10-500Hz 1G/3 axis | |
Humidity | 10 % - 90 %, non-condensing | |
Software | ||
Operating Software | Embedded Linux (Yocto Distribution) | Embedded Linux (Yocto Distribution) |
Browser | Chromium based HTML-5 | Chromium based HTML-5 |
Additional Software | QIWI Toolkit, optimized browser, with easy configuration and wide range of featuresnd breite Funktionspalette | |
Options (Further options on request) | ||
2x Ethernet, 1x RS232, 1x WIFI USB Dongle, anti-glare display, Customer logo on display frame | PoE (Power over Ethernet), 2x GBit Ethernet, 1x RS485, 2x GPO, WIFI USB Dongle, anti-glare display, customer logo on display frame |
WP Web Panel 7", 10", 15"
Innovative Web Panel with QIWI Software Toolkit
- Arm® i.MX6 1 or 2 Cores 800 MHz
- Arm® i.MX8M Mini 4 Cores 1.6 GHz
- Intel Atom® E3800 2 Cores 1.33 GHz/4 Core 1.91 GHz
Accessories
- No accessories
Software
- Embedded Linux (Yocto Distribution)
- Embedded Linux (Debian Distribution) for IntelAtom
- QIWI Toolkit
- Optional iniNET MicroBrowser Spider Control
- Optional CODESYS® SoftPLC
Technical Data
Function | WP 3x with Arm® i.MX6 | WP 4x with Arm® i.MX8M Mini | WP 5x with Intel Atom® E3800 |
Touch | |||
PCAP Multi-touch, flush glass surface | |||
Processor | |||
Arm® i.MX6 1 or 2 Cores 800 MHz | Arm® i.MX8M Mini 4 Cores 1.6 GHz | Intel Atom® E3800 2 Core 1.33 GHz / 4 Core 1.91 GHz | |
Memory | |||
RAM | 1 GB DDR3 (up to 2 GB) | 1 GB DDR4 (up to 2 GB) | 2 GB DDR3 (up to 8 GB) |
FLASH | 512 MB NAND Flash | 4 GB eMMC (up to 32 GB) | 16 GB eMMC (up to 32 GB) |
microSD Card Slot | microSD Card Slot | microSD Card Slot | |
Interfaces | |||
2x USB 2.0 (Host) 1x Ethernet (10/100) | 2x USB 2.0 (Host) 1x Ethernet (10/100/1000) | 2x USB 2.0 (Host) 1x Ethernet (10/100/1000) | |
Power supply | |||
24 V DC ±20 % | |||
EMC | |||
EN 61000-6-2 (immunity), EN 61000-6-4 (emission) | |||
Certifications | |||
CE | CE, (UL/cUL planned) | CE | |
Protection class/Mechanical | |||
Front IP65 in aluminium, backside IP20 in stainless steel/Fixing elements for quick mounting (portrait or landscape) | |||
Environment | |||
Operating temperature | 0 °C…+55 °C | ||
Cooling | Fanless | ||
Shock | EN 60068-2-27 | ||
Vibration | EN 60068-2-6 | ||
Humidity | 10 % - 90 % @39 °C, non-condensing | ||
Software | |||
Operating system | Embedded Linux (Yocto) | Embedded Linux (Yocto) | Embedded Linux (Debian) |
Browser | Chromium based HTML-5 or MicroBrowser (IniNet) | Chromium based HTML-5 | Chromium based HTML-5 |
Additional information | QIWI Toolkit, optimized browser, easy Configuration and wide range of features | ||
Options (Further options on request) | |||
Stainless steel front, 2x Ethernet, 1x RS232, 1x RS485 WIFI USB Dongle | Stainless steel front, 2x Ethernet, 1x RS232, WIFI USB Dongle | Stainless steel front, 2x Ethernet, 1x RS232, 1x RS485 WIFI USB Dongle | |
Display information | |||
Display size | |||
7.0” | 10.1” | 15.6” | |
Resolution | |||
1024 x 600 | 1280 x 800 | 1366 x 768 | |
Typ | |||
Opt. bond | Opt. bond | Air-gap | |
Format | |||
17 : 10 | 16 : 10 | 16 : 9 | |
Brightness | |||
450 cd/m² | 430 cd/m² | 400 cd/m² | |
Viewing angle | |||
85° / 85° / 85° / 85° | 80° / 80° / 80° / 80° | 85° / 80° / 85° / 85° | |
Colors | |||
16.7 Million | 16.7 Million | 16.7 Million | |
Dimensions WP3x / WP 4x | |||
200 x 132 x 48 | 265 x 187 x 41 | 405 x 254 x 60 |
Download
General-Safety-Instructions.pdf
QIWI_Software_Toolkit_Factsheet_EN.pdf
WP_Web_Panel_3x_4x_5x_Factsheet_EN.pdf
Web-Panel_WP-xxx_4x_User_Guide_902100B_EN.pdf
Quickstart_Guide_Web-Panel_WP-3x__4x__5x_902190A_EN.PDF
Web-Panel_WP-70_iMX6_User_Guide_902050A_EN.pdf
Web-Panel_WP-101_iMX6_User_Guide_902060A_EN.pdf
Video
- Performance compare (1) - QIWI Toolkit(1) - offers a performance optimized
- Easy onfiguration (2) - QIWI Toolk
- Quick setup (3) - QIWI Toolkit (3) - configure the device as a web brower, fast and easy
- Device Security (4) - QIWI Toolkit (4) - increased security of the web in terms of maleware and manipulation
CP Control Panel 6x
Control Panel 6x with multiple connectivity
- NXP Arm® i.MX8M Plus 4 Core, 1.6 GHz
- 1 GB DRAM DDR3L
- IPS, optical bonded
Accessories
- No accessories
Software
- Embedded Linux (Yocto Distribution)
- Optional CODESYS® SoftPLC
Technical Data
CP-70 | CP-101 | CP-156 | CP-156FHD | |
Display | ||||
IPS, optical bonded, see table below | ||||
Touch | ||||
Technology | PCAP, glossy glass surface | |||
Processor | ||||
CPU | NXP Arm® i.MX8M Plus Quad Core, 1.6 GHz | |||
Memory/Storage | ||||
DRAM DDR3L | 1 GByte, soldered (up to 4 GByte) | |||
eMMC | 4 up to 32 GByte | |||
NOR FLASH | 2 MByte (up to 16 MByte) | |||
FRAM | 128 kByte (up to 512 kByte) | |||
SD-Card | microSD Card Slot (up to SDXC-size) | |||
Interfaces | ||||
USB | 2x USB 2.0 (Host) | |||
Ethernet | 2x Ethernet (10/100/1000) independant, 1x TSN-capable | |||
CAN | 1x CAN-FD (isolated), optional: 2x CAN FD | |||
Serial Ports | 1x RS232, 1x RS485 (isolated), optional: 2x RS485 | |||
Expansion Plugs | optional: GPIO, HDMI, SPI, i²C, MIPI CSI 4-lane, Audio, M.2 Slot (Key E, B) | |||
More Features | ||||
Security | TPM | |||
Real-Time Clock | RTC with SuperCAP (>20 days) | |||
Mechanical | ||||
Construction | Front IP65 in aluminium, backside IP20 in stainless steel/aluminium | |||
Cooling | Fanless | |||
Mounting | Fixing elements for easy and quick cabinet mounting | |||
Environment | ||||
Certification | CE (UL/cUL planed) | |||
Power | 24 V DC ±20 % | |||
EMC | EN 61000-6-2 (immunity), EN 61000-6-4 (emission) | |||
Operating Temperature | 0 °C…+55 °C (optional -20 °C...+55 °C) | |||
Storage Temperature | -20 °C…+70 °C | |||
Humidity | 10 %-90 % @39 °C, non-condensing | |||
Altitude | Up to 9.800 ft (3000 m) | |||
Software | ||||
Operating System | Embedded Linux (Yocto Distribution) | |||
SOFT-PLC (Optional) | CODESYS® V3 | |||
Protocols (Optional) | EtherCAT, Modbus TCP/RTU, Profinet, Ethernet IP, CANopen, OPC UA, IIoT Libraries (MQTT, HTTPS, Azure, AWS, Google) | |||
Display Informationen | ||||
Display Size | ||||
CP-70: 7.0" | CP-101: 10.1" | CP-156: 15.6" | CP-156FD: 15,6" | |
Resolution | ||||
1024 x 600 | 1280 x 800 | 1366 x 768 | 1920 x 1080 | |
Format | ||||
17 : 10 | 16 : 10 | 16 : 9 | 16 : 9 | |
Brightness | ||||
450 cd/m² | 420 cd/m² | 400 cd/m² | 600 cd/m² | |
Dimensions | ||||
200 x 132 x 48 | 265 x 187 x 41 | 405 x 254 x 60 | 405 x 254 x 60 | |
Viewing Angle | ||||
85° / 85°/ 85° / 85° | 85° / 85°/ 85° / 85° | 85° / 85°/ 85° / 85° | 85° / 85°/ 85° / 85° | |
Colors | ||||
16,7 million | 16,7 million | 16,7 million | 16,7 million | |
Weight | ||||
0,83 kg | 1,3 kg | 3,5 kg | 3,5 kg | |
Consumption | ||||
5,5 VA | 8,9 VA | 16,8 VA | 20 VA |
CP Control Panel 7", 10", 15"
Control Panel with scalable performance
- NXP Arm® i.MX6 1-2 Cores, 800 MHz
- 1 GB DRAM DDR3L
- Capacitive multi-touch
Accessories
- No accessories
Software
- Embedded Linux (Yocto Distribution)
- Optional CODESYS® SoftPLC
Technical Data
CP-70 | CP-101 | CP-156 | |
Display | |||
See table below | |||
Touch | |||
Technology | PCAP, glossy glass surface | ||
Processor | |||
CPU | NXP Arm® i.MX6 1-2 Cores, 800 MHz | ||
Memory/Storage | |||
DRAM DDR3L | 1 GByte, soldered (up to 2 GByte) | ||
eMMC | (4 to 16 GByte) | ||
NAND/NOR FLASH | 512 MByte (256 MByte) / 1 MByte (up to 16 MByte) | ||
SRAM/FRAM | 128 kByte (up to 512 kByte)/ (up to 512 kByte) | ||
SD-Card | microSD Card Slot, exchangeable (up to 32 GByte SDHC) | ||
Interfaces | |||
USB | 2x USB 2.0 (Host) | ||
Ethernet | 2x Ethernet (10/100) independent | ||
CAN | 1x CAN (isol.) | ||
Serial Ports | 2x RS232, 1x RS485 (isol) | ||
Expansion plugs | GPIO, HDMI, SPI, I²C | ||
Mechanical | |||
Construction | Front IP65 in aluminium, backside IP20 in stainless steel | ||
Cooling | Fanless | ||
Mounting | Fixing elements for easy and quick cabinet mounting | ||
Environment | |||
Certification | CE | ||
Power | 24 V DC ±20 % | ||
EMV | EN 61000-6-2 (immunity), EN 61000-6-4 (emission) | ||
Operating temperature | 0 °C…+55 °C | ||
Storage temperature | -20 °C…+70 °C | ||
Humidity | 10 %-90 % @39 °C, non-condensing | ||
Altitude | Up to 6.500 ft (2000 m) | ||
Software | |||
Operating System | Embedded Linux (Yocto) | ||
SOFTPLC (optional) | CODESYS V3 | ||
Protocols (optional) | EtherCAT, Modbus TCP/RTU, Profinet, Ethernet IP, CANopen, OPC UA | ||
Display Information | |||
Display size | |||
CP-70: 7.0" | CP-101: 10.1" | CP-156: 15.6" | |
Resolution | |||
1024 x 600 | 1280 x 800 | 1366 x 768 | |
Format | |||
17 : 10 | 16 : 10 | 16 : 9 | |
Brightness | |||
450 cd/m² | 420 cd/m² | 400 cd/m² | |
Dimensions | |||
200 x 132 x 48 | 265 x 187 x 41 | 405 x 254 x 60 | |
Viewing angle | |||
85° / 85°/ 85° / 85° | 85° / 85°/ 85° / 85° | 85° / 85°/ 85° / 85° | |
Colors | |||
16.7 Million | 16.7 Million | 16.7 Million | |
Weight | |||
0.83 kg | 1.3 kg | 3.5 kg | |
Consumption | |||
5.5 VA | 8.9 VA | 16.8 VA |
Display-Line 7" i.MX8M Mini
Touch Panel 7"
- NXP i.MX8M Mini 4x Arm® Cortex®-A53 @1.6 GHz
- 1x Arm® Cortex®-M4 @400 MHz
- 4 GB LPDDR4-RAM
Accessories
- AC Connector Set
- AC Power Supply
- AC microSD
Software
- Embedded Linux (Yocto Distribution)
- Optional CODESYS® SoftSPS
Technical Data
Human-Machine-Interface | |||
Function | Standard-Layout | Options | |
Front | Aluminium front frame | ||
Display | 7" IPS, 1024 x 600 Pixel 450 cd/m² | ||
Touch | PCAP Multitouch | ||
Other | |||
Power supply | 24V DC ±20 % | ||
Power consumption | Linux running <6 W | ||
RTC buffering | CR1220 | ||
Debug | 1x Console | ||
Dimensions (wxhxd) | Alu front:200.1 x 131.9 x 46.5 mm | ||
Temperature range | 0 °C…+55 °C, ambient, non condensing | ||
Protection class | Front IP65, back IP20 | ||
CPU-Unit | |||
CPU | NXP i.MX8M Mini 4x Arm® Cortex®-A53 @1.6 GHz, 1x Arm® Cortex®-M4 @400 MHz | ||
Memory | |||
LPDDR4 | 4x GB | 1x GB, 2x GB | |
NOR-FLASH | 2x MB | ||
eMMC | 32 GB | 4 GB up to 64 GB | |
SD card | 1x microSD Card Slot | ||
nv Memory | 8 kB (64 kB) EERAM | ||
Communication | |||
Ethernet | 1x 1 Gbit/s, 1x 10/100 Mbit/s | ||
USB | 2x 2.0 Host, 1x 2.0 OTG | ||
Serial | 1x RS232, 1x RS485 | ||
CAN | 1x CAN 2.0 B | ||
DIO | 4x DIO (24 V/up to 800 mA) | ||
Software | |||
Bootloader | U-Boot | ||
Operating system | Embedded Linux (Yocto Distribution) | ||
RTC | 5ppm accuracy |
Display-Line i.MX6 ULL
Scalable Touch Panels Format 5“
- NXP i.MX6 ULL 1x Arm® Cortex®-A7 @800 MHz
- Glass front, frameless, 5“ TFT
- 512 MB DDR3-RAM
Accessories
- AC Connector Set
- AC Power Supply
- AC microSD
Software
- Embedded Linux (Yocto Distribution)
- Optional CODESYS® SoftPLC
Technical Data
Human-Machine-Interface | |||
Function | Standard-Layout | ||
Glass front | Frameless | ||
Display | 5“ TFT, 800 x 480 Pixel, 450 cd/m² | ||
Touch | PCAP Multitouch | ||
Other | |||
Power supply | 24 V DC ±20 % | ||
Power consumption | Linux running <1,5 W | ||
RTC Buffering | CR1220 | ||
Debug | 1x Console | ||
Dimensions (WxHxD) | 130 x 89 x 38 mm | ||
Installation dimension (WxH) | 126 x 82 mm | ||
Temperature range | 0 °C...+60 °C, ambient, non condensing | ||
Protection class | Front IP65 | ||
CPU-Unit | |||
CPU | NXP i.MX6 ULL 1x Arm® Cortex®-A7 @800 MHz | ||
Memory | |||
DDR3-RAM | 512 MB | ||
NAND-FLASH | 512 MB | ||
NOR-FLASH | 1 MB | ||
eMMC | 4 GB | ||
SD-Card | 1x microSD Card Slot | ||
nv Memory | 8 kByte nvSRAM | ||
Communication | |||
Ethernet | 2x 10/100 Mbit/s | ||
USB | 2x 2.0 Host, 1x 2.0 OTG | ||
Serial | 1x RS232, 1x RS485 | ||
CAN | 1x CAN 2.0 | ||
DIO | 2x DIO (24 V/up to 800 mA) | ||
AIO | 2x AIN (0...24 V) | ||
Software | |||
Bootloader | U-Boot | ||
Operating system | Embedded Linux (Yocto Distribution) | ||
RTC | 5ppm accuracy |
Display-Line Pi-Tron CM4
Touch Panel 7" / available from Q2-2024
- Broadcom BCM2711 4x Arm® Cortex®- A72 @1.5 GHz
- 7" IPS Multitouch, 1024 x 600 Pixel 450cd/m2
- Aluminium front frame, front IP65
Software
- Raspian Linux
Technical Data
Human-Machine-Interface | |||
Function | Standard-Layou | Options | |
Front | Aluminium front frame | ||
Display | 7" IPS, 1024 x 600 Pixel 450 cd/m² | ||
Touch | PCAP Multitouch | ||
Other | |||
Power supply | 24V DC ±20 % | ||
Power consumption | Linux running 7,2 W - 13,4 W | ||
RTC buffering | CR2032 | ||
Debug | 1x Console | ||
Dimensions (WxHxD) | Alu-Front:200,1 x 131,9 x 46,5 mm | ||
Temperature range* | 0 °C…+55 °C, ambient, non condensing | ||
Protection class | Front IP65, back IP20 | ||
CPU-Unit | |||
CPU | Broadcom BCM2711, 4x Arm® Cortex®-A72 @1.5 GHz, 3D Video Engine | ||
Memory | |||
LPDDR4 | 2x GB | 1x GB, 4x GB, 8 GB | |
eMMC | Compute Module CM4: 16 GB | CM4: lite/8 GB/32 GB (lite: without eMMC only with microSD-Card) | |
SD-Card | CM4 lite: 1x microSD Card Slot for Operating System, CM4 8GB, 16 GB, 32 GB: 1x micro SD Card Slot for data | ||
EEPROM* | 4 kB (32kb) | ||
Communication | |||
Ethernet | 1x 1 Gbit/s, 1x 10/100 Mbit/s | ||
USB | 2x 2.0 Host, 1x 2.0 OTG: only to programm eMMC | ||
WLAN/Bluetooth® | Optional 2.4 GHz/5.0 GHz, IEEE 802.11 b/g/n/ac wireless BT 5.0, BLE | ||
Serial | 1x RS232, 1x RS485 | ||
CAN | 1x CAN 2.0B/FD | ||
DIO | 4x DIO (24 V/up to 800 mA) | ||
Display | |||
LCD Interface | 1x HDMI 2.0 (up to 4Kp60 - HDMI0) | ||
Software | |||
Operating system | Raspian Linux | ||
RTC | ± 1ppm accuracy | ||
*Preliminary data |
TM Touch Monitor
Customized touch monitor solutions with HDMI connection
- From 5“ to 15.6“
- HDMI connection for various resolutions including scaling
- Custom housing and mounting systems
Accessories
- No accessories
Software
- No software
Technical Data
Touch-Monitor | |
Display | |
Size | 5" - 15." Displays (wide format) |
Graphics processor | Realtek RTD2483 |
Touch | |
Technology | PCAP, multi-touch with glass surface |
Interfaces | |
HDMI | HDMI Type A, HDMI input with multiple resolution support. Image scaling can be enabled as an option. |
Touch | USB 2.0 Type B, acts as HID device |
Power supply | 24 V DC ±20 % |
Mechanical | |
Housing design | Customized housing design for cabinet installation or stand-alone version for VESA- or support arm mounting, depending on customer needs |
Environment | |
Certification | According to customer needs |
Operating Temperature | 0 °C …+50 °C |
Storage Temperature | -25 °C …+60 °C |
Humidity | 5 % - 95 % non-condensing |
OEM Branding | |
Front | Optional OEM Logo on cover glass |
Labeling | Optional OEM type label according to customer specification |
